電動(dòng)三輪車(chē)
| Size | Length * width * height |
2200MM*760MM*1300MM Handlebar height1200MM |
| Wheelbase (Front/Rear) | 1520MM | |
| Rear wheelbase | 600MM | |
| Minimum ground clearance | 160MM | |
| Seat height | 750MM | |
| Shelf height | 630MM | |
| Radius of gyration | 2250MM | |
| performance | Single charge travel distance | ≦80KM |
| Top speed | ≧50KM/H | |
| Gradeability | 30% | |
| Maximum load | 100KG | |
| Vehicle | Vehicle weight | 146KG(Without battery） |
| Swing angle | Tilt 30 degrees left and right | |
| Brake type | Front and rear disc brakes | |
| Tire specifications | Front:90/90-12 Rear:130/70-12 | |
| Motor | Type | DC, brushless, permanent magnet, Intermediate differential motor |
| Rated power | 1500W | |
| Rated voltage | 60V | |
| Efficiency (%） | 90% | |
| Battery Pack | Types | Lithium ternary lithium battery system |
| Capacity | 50AH | |
| Rated voltage | 60V | |
| Undervoltage | 51V | |
| Controller | Types | Sine wave vector |
| Undervoltage protection | 54V | |
| Peak current | 50A | |
| Rated voltage | 60V |
